SP1713/P Compatible IP68 Y17 Connector, Male Flange Socket, Solder Type, Alternative to: RHTOY17B3

Series P/N: RHTOY17B3

RHT provides a wide selection of Y13, Y17, and Y21 IP68 Waterproof Circular Connectors, supporting reliable electrical connections for industrial equipment, outdoor devices, and automation systems.

With various connector types, sizes, contact configurations, and mounting options, our products meet different wiring and installation requirements.

As a connector solutions partner, RHT works closely with engineering teams to understand technical needs and provide suitable waterproof circular connector solutions from sample evaluation and design verification to product integration and project implementation.

2D(PDF)Drawing

3D(IGS / STP)Drawing

Product parameter:

SP1713/P Compatible IP68 Y17 Connector, Male Flange Socket, Solder Type, Alternative to: RHTOY17B3

Features

-IP68 Rating: This indicates that the connector is dust-tight and can withstand immersion in water beyond 1 meter depth, making it suitable for outdoor or harsh environment applications.

-Male Socket: This specifies the gender of the connector, indicating it has pins that insert into a female connector or socket.

-Flange Mount: The connector is designed to be mounted onto a panel or device with a flange, providing a secure attachment.

-Solder Connection: This denotes how the wires are attached to the connector. In this case, soldering is required, where wires are soldered directly to the connector's terminals.

Applications

1.Outdoor Electronics

2.Marine and Boating

3.Industrial Equipment

4.Automotive

Specifications

Material & SPEC.

1.Shell Material: PPO,PA66 UL94V-0

2.Insulation Materials: PPS, High Temperature 260°C

3.Contact: Brass,Gold-plated

4.Insulation resistance: 2000MΩ

5.Number of poles: 2~9 poles
