XLR Plug Connector:RHTAYLR-P08

Series P/N:RHTAYLR-P08

RHT provides a wide selection of XLR Connectors, supporting reliable audio signal transmission and connections for professional audio equipment, microphones, mixing consoles, amplifiers, stage sound systems, and recording equipment.

With various connector types, pin configurations, mounting options, and structural designs, our products meet different audio connection requirements, installation conditions, and equipment integration needs.

RHT works closely with engineering teams to understand technical requirements and provide suitable XLR Connector solutions, from sample evaluation and specification confirmation to design verification and product integration.

2D(PDF)Drawing

3D(IGS / STP)Drawing

Product parameter:

Features

-Noise Reduction: The XLR connector is designed for balanced audio transmission, which helps reduce electromagnetic interference (EMI) and ground loop hum, ensuring a clean and clear audio signal.

-Three Pins: The three-pin design (positive, negative, and ground) ensures a balanced connection, minimizing the risk of signal degradation, especially over long cable runs.

-High-Quality Construction: XLR plugs are made from durable materials such as brass, aluminum, or steel, making them resistant to physical wear and tear.

-Long Lifespan: The robust design ensures that XLR plugs can withstand frequent use in demanding environments, such as concerts, broadcast studios, and field recordings.

Applications

1.Microphone Connections

2.Professional Audio Systems

3.Lighting Control Systems

4.Security and Communication Systems

Specifications

Number of contacts: 3

Contact Resistance: ≤ 3 mOhms

Insulation Resistance Initial: > 2 GOhms

After Damp Heat Test: > 1 GOhms

Dielectric Strength: 1500 V dc

Rated current : 16 A
