XLR Plug Connector :RHTAYLR-P03

Series P/N:RHTAYLR-P03

RHT provides a wide selection of XLR Connectors, supporting reliable audio signal transmission and connections for professional audio equipment, microphones, mixing consoles, amplifiers, stage sound systems, and recording equipment.

With various connector types, pin configurations, mounting options, and structural designs, our products meet different audio connection requirements, installation conditions, and equipment integration needs.

RHT works closely with engineering teams to understand technical requirements and provide suitable XLR Connector solutions, from sample evaluation and specification confirmation to design verification and product integration.

2D(PDF)Drawing

3D(IGS / STP)Drawing

Product parameter:

Features

-Heavy-Duty Housing: XLR plugs are typically constructed from high-quality metal alloys such as brass or aluminum, ensuring a durable and robust design that can withstand physical wear and tear.

-Noise Reduction: XLR plugs are widely used for balanced audio transmission, which helps in reducing electromagnetic interference (EMI) and ground loop noise, crucial for maintaining high-quality audio signals over long cable runs.

-High-Quality Audio: The design allows for clear, distortion-free audio in professional environments, ensuring that sound systems maintain integrity even in challenging environments.

-Prevents Unintended Disconnections: This is particularly important for ensuring continuous audio signal during performances, events, and recordings, where a sudden disconnection can disrupt the entire system.

Applications

1.Microphone Connections

2.Audio Mixing Consoles

3.Speakers and Amplifiers

4.Broadcasting and Recording Studios

Specifications

Number of contacts: 3

Contact Resistance: ≤ 3 mOhms

Insulation Resistance Initial: > 2 GOhms

After Damp Heat Test: > 1 GOhms

Dielectric Strength: 1500 V dc

Rated current : 16 A
