MOLEX 50802-8000 2.54mm Molex 5240 Series Wire-to-Wire Connector – Alternative to RHTAYM1-2.54

Series P/N:RHTAYM1-2.54

RHT provides a wide selection of Wire to Board Connectors and Wire to Wire Connectors, helping engineers develop reliable and efficient wire connection solutions.

With various pitches, wire sizes, pin configurations, mounting options, and specifications, our connectors can meet different design requirements and application challenges.

As a connector solutions partner, RHT’s engineering team works closely with design teams to understand technical requirements, discuss development needs, and provide suitable solutions from sample evaluation and prototype validation to project development and mass production.

2D(PDF)Drawing

3D(IGS / STP)Drawing

Product parameter:

MOLEX 50802-8000 2.54mm Molex 5240 Series Wire-to-Wire Connector – Alternative to RHTAYM1-2.54

Features

-Termination Style: Designed for crimp-style wire termination, where the stripped ends of wires are inserted into the connector's contacts and crimped to secure them in place. This termination method provides a secure electrical connection and strain relief for the wires, preventing accidental disconnection.

-Current Rating and Voltage: The connector is rated for specific current carrying capacities and voltage levels, ensuring compatibility with the electrical requirements of various applications. These ratings are typically specified by the manufacturer.

-Keying and Polarization: To prevent mismating and ensure proper alignment during connection, the Molex 5240 connector may feature keying or polarization features. These ensure that connectors can only be mated in the correct orientation, maintaining electrical integrity and preventing damage.

-Environmental Considerations: Designed to operate reliably in various environmental conditions, including temperature fluctuations, vibration, and mechanical stress. This makes the Molex 5240 connector suitable for use in applications where durability and reliability are critical.

Applications

1.LED Lighting Systems

2.DIY Electronics and Prototyping

3.Telecommunications

4.Medical Devices

Specifications

2.54mm Molex 5240 Type Wire To Wire Connector

Order information:

RHTAYM1-2.54

Pitch:2.54mm

pins:2~12

MH=Male Hosing / FH=Female Hosing / MT=Male Terminal / FT=Female Terminal
