MOLEX 39000038 4.20mm Molex 5557 5559 Wire To Board Connector :RHTAY4.20

Series P/N: RHTAY4.20

RHT provides a wide selection of Wire to Board Connectors and Wire to Wire Connectors, helping engineers develop reliable and efficient wire connection solutions.

With various pitches, wire sizes, pin configurations, mounting options, and specifications, our connectors can meet different design requirements and application challenges.

As a connector solutions partner, RHT’s engineering team works closely with design teams to understand technical requirements, discuss development needs, and provide suitable solutions from sample evaluation and prototype validation to project development and mass production.

2D(PDF)Drawing

3D(IGS / STP)Drawing

Product parameter:

MOLEX 39000038

Features

-Polarization: Designed with polarization features to prevent incorrect insertion and ensure proper alignment between the connector and PCB. This helps avoid damage and ensures reliable connections.

-Locking Mechanism: Many models include a locking mechanism (such as a latch or friction lock) to secure the connector to the PCB, preventing accidental disconnection due to vibrations or pulling.

-Voltage Rating: Supports a specific voltage range suitable for the intended application, ensuring safe and reliable operation.

-Current Capacity: Designed to handle a specific current capacity, ranging from moderate to high current levels depending on the series (5557 or 5559).

Applications

1.Power Supply and Distribution

2.Industrial Equipment and Machinery

3.Automotive Electronics

4.Telecommunications and Networking

Specifications

Electrical Specification:

Rated Voltage: 300V AC.DC

Rated Current: 9A

Contact Resistance: 0.015Ω max

Insulation Resistance: 1000MΩ min

Withstand voltage: 1500V AC/MIN
