1.0mm hinged lock SMT H2.0mm bottom contacts FPC/FFC connectors :RHTAY40M-2.0

Series P/N: RHTAY40M-2.0

RHT provides a wide selection of FFC/FPC Connectors, helping engineers develop reliable and efficient flexible connection solutions.
With various pitches, contact configurations, mounting options, and specifications, our connectors can meet different design requirements and application challenges.
As an FFC/FPC connector solutions partner, RHT’s engineering team works closely with design teams to understand technical requirements, discuss development needs, and provide suitable solutions from sample evaluation and prototype validation to project development and mass production.

2D(PDF)Drawing

3D(IGS / STP)Drawing

Product parameter:

Features

-Connector Type: Designed with a hinged lock mechanism, ensuring secure mating and preventing accidental disconnection of Flexible Printed Circuits (FPC) or Flexible Flat Cables (FFC).

-Mounting Style: Surface Mount Technology (SMT), allowing for direct placement on the surface of a PCB (Printed Circuit Board), which simplifies assembly and saves space.

-Contact Type: Bottom contacts, where the contacts are located on the bottom side of the connector, suitable for connecting to corresponding pads on the PCB

-Height: H2.0mm refers to the height profile of the connector, which is important for determining the overall space required on the PCB.

Applications

1. Telecommunications

2. Automotive Electronics

3. Medical Devices

4. Industrial Equipment

Specifications

1.0mm hinged lock SMT H2.0mm bottom contacts 4-35P FPC/FFC connectors

Order Information

RHTAY40M-2.0-XX-T-L-R

XX-No.of 04 ~ 35pin

T-Horizontal SMT
