0.5mm ZIF SMT H1.2mm bottom/upper contacts FPC/FFC connector :RHTAY42D-1.2

Series P/N: RHTAY42D-1.2

RHT provides a wide selection of FFC/FPC Connectors, helping engineers develop reliable and efficient flexible connection solutions.
With various pitches, contact configurations, mounting options, and specifications, our connectors can meet different design requirements and application challenges.
As an FFC/FPC connector solutions partner, RHT’s engineering team works closely with design teams to understand technical requirements, discuss development needs, and provide suitable solutions from sample evaluation and prototype validation to project development and mass production.

2D(PDF)Drawing

3D(IGS / STP)Drawing

Product parameter:

Features

-Pitch and Size: The connectors have a pitch (distance between adjacent contacts) of 0.5mm, suitable for applications requiring fine pitch connections. The overall height (H) is approximately 1.2mm, providing sufficient clearance for the flexible circuits and ensuring compatibility with standard PCB layouts.

-ZIF Mechanism: These connectors feature a Zero Insertion Force (ZIF) mechanism, which allows for insertion and removal of the flexible circuits without applying significant force. This minimizes the risk of damaging the circuits during assembly or maintenance, making them ideal for applications where frequent connection/disconnection is necessary.

-Bottom/Upper Contact Design: These connectors can have both bottom and upper contacts, where the contact points are located on both the underside and top side of the connector. This dual contact design facilitates versatile connectivity options, enabling direct contact with the PCB pads on either side for optimized electrical performance and reliable signal transmission.

-Surface Mount Technology (SMT): Designed for surface mount assembly, these connectors are soldered directly onto the surface of a PCB. This allows for efficient and automated assembly processes, ensuring secure mechanical attachment to the board and minimizing assembly time and costs.

Applications

1. Telecommunications

2. LED Lighting

3. Testing and Measurement Equipment

4. Military and Aerospace

Specifications

0.5mm ZIF SMT H1.2mm bottom/upper contacts 4-35P FPC/FFC connector

Order Information

RHTAY42D--1.2-XX-T-U-R

XX-No.of 04 ~ 35pin

Height: 1.2mm

T-SMT Pin
