    Industrial Ethernet M12 Connectors :RHTOY25-M12

    Series P/N:RHTOY25-M12

    RHT provides a wide selection of Circular Connectors, supporting reliable electrical connections for industrial equipment, electronic devices, automation systems, communication equipment, and various electrical applications.

    With various connector types, sizes, contact configurations, pin arrangements, and mounting options, our products can meet different wiring layouts, installation requirements, and equipment integration needs across a wide range of applications.

    As a connector solutions partner, RHT works closely with engineering teams to understand technical requirements, discuss specific application needs, and provide suitable circular connector solutions from sample evaluation and design verification to product integration and project implementation.



    Inquire Now
    Share
    Product parameter:

    Features

    -Circular Design: M12 connectors have a circular shape with a threaded coupling mechanism, which ensures a secure and robust connection. This design also allows for quick and easy installation and removal.

    -Variety of Configurations: M12 connectors come in various configurations, including 3-pin, 4-pin, 5-pin, 8-pin, and more. The number of pins determines the types of signals (power, data, or both) that can be transmitted through the connector.

    -IP Ratings: They are available in different IP ratings, typically IP67 or IP68, which indicates their resistance to dust and water ingress. IP67 ensures protection against temporary immersion in water, while IP68 provides protection against continuous immersion.

    -Material Options: M12 connectors are typically made from materials such as stainless steel, brass, or high-grade plastics. These materials offer durability and resistance to corrosion, making them suitable for harsh industrial environments.

    -Plug-and-Play Design – Quick and easy to connect and disconnect.


    Applications

    1.Industrial Automation

    2.Fieldbus and Industrial Ethernet

    3.Transportation

    4.Telecommunications

    5.Agriculture


    Specifications

    M12   Circular Connector (Safty apporval : UL / Water proof  Ip≥55 )
    Subminiature Circular Connector are widely useed for the Hi-Tech trade.   thread type. Used in the installation of the panel, small, exquisite and   sensitive.

    Order Information:
    RHTOY25-M12
                            (1) (2)(3)
    1- M12:  M12 Shell Size
    2- 2:   2 pins     (2,3,4,5,6,pins)
    3- F1-Plug Socket  F2-Docking Plug   Pin  M1-Receptacle Pin  M2-Through-wall Receptacle Pin


    Technical Documents

    Please contact us for more information.
