RHT is a leading Rising Clamp PCB Terminal Block Supplier specializing in high-performance connectivity solutions for industrial, automotive, and telecommunications sectors. With a focus on innovation and reliability, RHT combines cutting-edge manufacturing processes with stringent quality control (ISO 9001 certified) to deliver products that exceed industry standards.

Product Description: Rising Clamp PCB Terminal Block

RHT’s Rising Clamp PCB Terminal Blocks facilitate secure wire-to-board connections without soldering. These terminals feature a unique spring-actuated clamp mechanism that simplifies installation while ensuring vibration-resistant, gas-tight connections. Ideal for high-density PCB designs, they support applications demanding frequent maintenance or modular assembly.

Key Features & Specifications

1. Rising Clamp Mechanism

• Material: Zinc-plated steel clamp for corrosion resistance and high clamping force.

• Operation: Screw-driven clamp lifts vertically to secure wires (0.2–3.6 mm² solid/stranded cables).

• Torque Control: M2.5 or M3 screws with precise torque settings (e.g., 0.5 Nm) prevent over-tightening.

2. Electrical & Thermal Performance

• Current/Voltage Rating: Up to 24A/250V or 10A/300V (depending on model).

• Dielectric Strength: Withstands >2.5 kV impulse voltage.

• Temperature Range: Operates reliably from -40°C to +105°C.

3. Mechanical Design

• Housing: UL94-V0 flame-retardant polycarbonate or PA66 for superior insulation and durability.

• Terminal Contacts: Tinned nickel-plated brass or copper for low resistance and oxidation prevention.

• Pitch Options: 5.0 mm pitch for space-optimized layouts.

4. Mounting & Integration

• PCB Compatibility: THR (Through-Hole Reflow) or SMT mounting; recommended hole size: 1.3 mm.

• Anti-Wicking Design: Guided pins prevent solder wicking during reflow.

• Stackable Configuration: Modular poles (2P–24P) allow customizable configurations.

5. Safety & Compliance

• Certifications: UL94-V0, RoHS, and REACH compliant.

• Safety Barriers: Insulated barriers prevent accidental contact and short circuits.

Applications

RHT’s terminal blocks are engineered for:

• Industrial Automation: Control panels, motor drives, and sensors.

• Transportation: Rail systems, automotive ECUs, and aviation electronics.

• Energy & Telecom: Power supplies, frequency converters, and server farms.

• Medical/Military Equipment: High-reliability systems requiring vibration resistance.

Why Choose RHT as Your Rising Clamp PCB Terminal Block Supplier?

• Customization: Tailored solutions for pitch, pole count, and materials (e.g., brass, copper, or steel alloys).

• Quality Assurance: Rigorous testing (AOI, flying probe, electrical validation) ensures zero defects.

• Global Support: Technical expertise and rapid response for design optimization and troubleshooting.

• Sustainability: Eco-friendly manufacturing aligned with ISO 14001 standards.
